3528 LED Strip Series with high brightness, low power consumption. The Strips are easy to install, even for the nonprofessional. Also the Strips are safe for installation indoors and outdoors due to the low voltage.
| Part No. | Voltage | Description | PCB | CCT | CRI | Lumen/SMD | IP Grade | Warranty |
|---|---|---|---|---|---|---|---|---|
| SELS-3528W120-12AWW | 12V | 240pcs 3528SMD/M 18W/M | 10mm Double Side | WW 2800-3200K | ≥80Ra | 7-8LM | IP20-Non Waterproof IP65-Silicon Glue IP68-Silicon Tube +Silicon Glue | 3 Years |
| SELS-3528W120-24AWW | 24V | |||||||
| SELS-3528W120-12ANW | 12V | NW 4000-4500K | ||||||
| SELS-2835W120-24ANW | 24V | |||||||
| SELS-3528W120-12APW | 12V | PW 6000-6500K | ||||||
| SELS-3528W120-24APW | 24V |
Super bright 3528 SMD top LED, high intensity and reliability.
Continuous length, packed with 5 meter.
Cut table every 3/6 LEDs along the cutting marks, according to practical requirement.
Flexible ribbon for curving around bends.
Ultra-bright but running at low temperature.
High brightness, low power, long life, easy installation.
Completely smooth and even light spread, solving the uneven luminous problem, decorative effect is brilliant.
LED Strip Light can be widely used in accent lighting, backlighting, task lighting, and decorative lighting applications. And increased luminous efficacy and longer lifespan allows the Strip light be used in applications such as high brightness task lighting, fluorescent and halogen lighting fixture replacements, indirect lighting applications, set and costume design, and even growing plants lighting.
1. Architectural decorative lighting
2. Archway, canopy and bridge edge lighting
3. Amusement park, theater and aircraft cabin mood lighting
4. Emergency hallway lighting
5. Auditorium walkway lighting
6. Stairway accent lighting
7. Concealed lighting
8. Back lighting for signage letters
9. Channel letter lighting
10. Emergency exit path lighting
11. Cove lighting
12. Landscape outlines and signal lighting, Advertisements signs
| Data sheet | |
|---|---|
| Application | Constant voltage |
| CCT | NW 4000-4500K |
| CRI | 80 |
| IP. | 65 |
| LED Type | 3528 |
| Lumen/m | 1620-1800 |
| Lumen/W | 90-100 |
| Number LED/m | 240 |
| Power Supply | 24V |
| W/m | 18 |
